Width 20mm PMMA PC LED Strip Aluminium Profile High 27mm 6063 T5

Product Categories
K&C LIGHTING TECHNOLOGY LIMITED
Contact Now

Width 20mm PMMA PC LED Strip Aluminium Profile High 27mm 6063 T5

  • 1
  • 2

Brand Name : K&C

Model Number : K30

Certification : ROHS

Place of Origin : Guangdong China

MOQ : 100meters

Price : Negotiate

Payment Terms : T/T, Western Union, L/C

Supply Ability : 100Tons/Month

Delivery Time : 3-10 work days

Packaging Details : Inner Clear PE bag+EPE FOAM+Carton Box

Finished color : Silver, Black, White

Length : Standard 2m, 2.5m or Max.6m on request

Indstallation : Mounted

Material : 6063 t5 Aluminum Alloy

Diffuser : PMMA/PC, Opal/Frosted/Clear

Process : Extrusion

Shape : Flat

Packing : PE bag + Carton / customized package

Contact Now

Wide Flat Mounted LED Strip Aluminium Profile And PMMA Opal Cover

Surface-mounted high-quality anodized Flat LED Strip Aluminium Profile which is dedicated for standard led stripe light up to 16m width. The profile is performing as the heat sink to the LED strip and appears as nice, stylish housing for the LED strip. We propose to our customers three different diffusers: opal, frosted and transparent. We also offer several different accessories such as PMMA cover, mounting clips, and end caps which make it look professional and modern.

Application
- Kitchen cabinets LED Lighting
- Furniture LED Lighting
- Store shelf LED lighting
- Home using residential building decorations lighting
- Exhibition booth LED lighting

Assembly
- Mounted to the surface with appropriate mounting clips

Additional information
- The LED profile is suitable for bending into gentle arches, in the plane adjacent to the LED strip
- Can be equipped with transparent and frosted covers
- Space for LED strip up to 16mm width

Main Specifications

Model No.: K30
Item Type: LED Strip Aluminium Profile
Dimensions: (W)20*(H)27mm
Standard length: 2m/pcs
Customized-length: Available on request
Suitable for led strip: PCB width up to 16mm
Material: 6063 T5 Aluminum Alloy
Treatment:

Sandblasting oxidation
Finished color: Silver, black, white
Diffuser material: PMMA/PC
Diffuser finished: Opal/Frosted/Clear/ Black
Accessories: End caps, clips
Installation: Surface-mounted
Standard Package: Inner Clear PE bag+EPE FOAM+Carton Box
Customized Package: Available on request
Handling time Samples within 3 working days
Batch order 3-15 working days upon stocks
Shipment By sea, by air, by express for option


Drawing:
Width 20mm PMMA PC LED Strip Aluminium Profile High 27mm 6063 T5
Installation
Width 20mm PMMA PC LED Strip Aluminium Profile High 27mm 6063 T5
Application

Width 20mm PMMA PC LED Strip Aluminium Profile High 27mm 6063 T5

Recommendation
Width 20mm PMMA PC LED Strip Aluminium Profile High 27mm 6063 T5

Catalogue
Width 20mm PMMA PC LED Strip Aluminium Profile High 27mm 6063 T5

FAQ:
Q: How to cut the led aluminum profile?
A: Led aluminum profile is very strong, it cannot cut by scissor-like led strip light. It has to use a saw to cut. And we suggest using a precision sawing machine then can cut the aluminum profile in the accurate size.

Q: How many kinds of led aluminum profile cover?
A: We have has 2 kinds covers, One is PMMA cover (Opal, semi-clear, clear) The other one is PC cover ( Frosted, clear).

Q: How many colors of led aluminum profile available? Collapse
A: We can offer 3 kind colors of led aluminum profile. White, black, and sliver.

Q: How to use led aluminum profile for cabinet light?
A: 1. Fixed the led strip light into the led aluminum profile.
2. Fixed the led aluminum profile under the cabinet.
3. Connect the power supplier with led strip light.

Q: How to make a led aluminum profile connector?
A: We can offer some kinds of led aluminum profile connectors to you. Of course, some clients can use a soldering machine to connect the led aluminum profile.
